| Body & Bonnet Material |
ASTM A105 – Forged Carbon Steel ASTM A182 F304/F304L – Forged Stainless Steel ASTM A182 F316/F316L – Forged Stainless Steel ASTM A182 F11/F22 – Alloy Steel |
|---|---|
| Trims / Working Parts |
ASTM A276 T-410 (SS-410 – 13% Cr. Steel) ASTM A276 T-304/304L (SS-304 / SS-304L) ASTM A276 T-316/316L (SS-316 / SS-316L) Stellited – ST6 |
| Gland Packing | PTFE Virgin / Carbon Filled Teflon / Grafoil Ring / Graphite Ring |
| Gasket | SS304 / SS316 Spiral Wound with Graphite Filled |
| Bolting | ASTM A193 Gr. B7 / B8 / B8M / ASTM A194 Gr. 2H |
| Design Standard | API 602 / BS 5352 / ASME B16.34 |
| Testing Standard | API 598 |
| Flange End Standard | ASME B16.5 / Face to Face ASME B16.10 |
| End Connection |
Flanged End to ASME B16.5 (150# / 300# / 600# – Flanges
Welded) Screwed / Threaded End to ASME B1.20.1 Socket Weld End to ASME B16.11 Butt Weld End to ASME B16.25 |
| Operation | Manual / Electric Actuator |
Forged Steel Gate Valves are designed for high-pressure and high-temperature applications where maximum durability and leak-free performance are essential. Made from high-strength forged steel, these valves provide excellent resistance to corrosion, thermal stress, and mechanical wear. They offer smooth, unobstructed flow with minimal pressure drop, making them ideal for oil & gas, petrochemical, chemical, and power generation industries. Their compact design ensures easy installation, while the robust construction guarantees long operational life with minimal maintenance. Forged Steel Gate Valves are a reliable solution for critical shutoff applications demanding superior strength and long-term performance.
